Description
VCO 1 – , Pulse and Triangle waves with unique modifiers and direct FM control. Ultra Saw makes for huge sounds, Metalizer adds complex harmonics to the triangle wave. FM generates rich tones.
VCO 2 – Selectable waveform between sine, saw and square. Multiple tuning modes for fine, coarse or LFO operation.
Oscillator Mixer allows for mixing the levels of the individual waveforms of the oscillator 1 and 2, the noise generator and the external inputs.
Steiner-Parker Multimode Filter – Beefy filter with Low Pass, High Pass, Band Pass, and Notch modes. Resonance can be pushed into self oscillation.
4-Stage ADSR Type Envelope generator
The Brute Factor can add subtle drive effects to full blown intermodulation havoc.
AD Envelope – This modulator can generate AD, AHR or loopable envelopes. Its Attack and Decay times are CV-controllable, too.
Patchbay – 48 CV inputs and outputs to control many elements of the synthesizer and sequencer. Some utility modules provide extended possibilities.
Two LFOs – Both LFO supply 6 waveforms and can run in sync to the Sequencer. Very fast rates can be obtained.
3-track, 64-step sequencer – The sequencer controls Pitch, Gate, Velocity and Pressure. Use Seq 2 or Seq 3 to generate other types of signals : Gates, CV, Pitch, LFOs, Envelopes. Real-time and step editing are available.
Pads and Encoders – 16 Pressure and Velocity sensitive pads can be used as a keyboard or to enter steps in the sequence. Encoders are used to edit the values for each step.
64 pattern memories are available, organized in four banks. Create a chain of patterns to build longer patterns or even full songs.
Sync – Synchronize to external MIDI, USB or analog clock.
Arp/Loop – Generate arpeggios on the keys or loop a portion of the sequence. Everything stays in sync when you exit the loop, perfect for performance.
Audio In/Out – Line and headphones outputs.
MIDI In/Out – Connect and sync MiniBrute to any DAW or hardware MIDI equipment.
USB In/Out – Control MiniBrute from your DAW or use it as a master keyboard
